Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Ding
color:
yellow, black
Packaging & Delivery
Packaging Details
according to customer requirement
Lead Time :
according to the quantity

Specifications

fiberglass abrasive discs
1. high tensile strength
2. deflection resistance
3. excellent high-speed cutting resistance

fiberglass abrasive discs is punched from fiberglass cloth for grinding wheel which coated with phenolic and epoxy resin .when necessary , coating with non-woven fabric .black paper and PE It is the best base material for resin bond grinding wheel with the features of high tensile strength and deflection resistance, it is nice performance to link up with abrasive,meanwhile,it is the features of excellent high-speed cutting resistance and heat resistance.



Application:

grinding_wheel_cutting_disc_cut_off_wheel



Specification:



5 density per inch:
CNG160-5*5
CNG210-5*5
CNG260-5*5
CNG320-5*4
CNG330-5*5
CNG380-5*4

6/7 density per inch:
CNG190-6*6
CNG230-6*6
CNG145-7*7

8 density per inch:
CNP260-8*8
CNP330-8*8
CNP420-8*8

9 density per inch:
C(E)NP250-9*9
CNP275-9*9
C(E)NP300-9*9

10 density per inch:
CNG65-10*10
CNG90-10*10
CNG330-10*10


11/18 density per inch:
CNP260-11*11
C(E)NP330-11*11
CNP180-18*18

14/19/20 density per inch:
CNP56-14*14
CNG85-14*14
CNG125-14*14
CNP145-14*14
ENP105-19*19
ENP210-20*20



Expression of specification
compositionmeshstructureweight-warp*weft/OD*ID+surfance
CNG190-6*6/396*33+VW



Taking CNG190-6*6/396*33V+W for example:
Expression of the cloth same as above
OD :outside diameter is 396
ID: Inside diameter is 33




surface : V+W means coated with non woven fabric +wax paper W means plain +
wax paper :P means coated with black paper .
PE means +PE as separator; B means black color
